VIBRA® Bullet Magnets
High-efficiency inline magnetic separators designed for vertical pneumatic pipelines. The aerodynamic bullet shape captures ferrous contaminants from powders and granules without restricting flow.
- Aerodynamic Flow-Thru Design
- Vertical Line Protection
- High-Intensity Magnetic Core
- Easy Clean Door
Why Choose VIBRA® Bullet Magnets?
Designed to protect your equipment and ensure product purity in demanding industrial environments
Optimized for Pneumatic Systems
These magnets are specifically engineered for gravity and pneumatic pipelines where maintaining flow rate is critical. The aerodynamic stainless steel nose cone prevents material bridging and blockages, allowing bulk powders, flour, and granules to flow freely around the magnet while it extracts ferrous metal.
Superior Contamination Retention
Iron particles are attracted to the central magnetic cone and are securely retained behind specialized triangular flanges (pole pieces). This design feature prevents “wash-off,” where the velocity of the product flow might otherwise knock collected metal back into the stream, ensuring consistent purity.
Sanitary & Rugged Construction
Built for hygiene-critical industries like food and pharmaceuticals, VIBRA® Bullet Magnets feature a fully welded 304 or 316 stainless steel housing. This robust construction withstands high pneumatic pressures and abrasive materials while eliminating crevices where bacteria could grow.
Technical Specifications
Complete technical data for engineering and procurement teams
Housing Material
304 or 316 Stainless Steel (Fully Welded)
Magnet Type
Ceramic (Standard) or Rare Earth (High Intensity)
Shape
Aerodynamic Cone / Bullet
Line Sizes
Standard 3″ to 12″ (Custom sizes available)
Flow Type
Vertical Pneumatic or Gravity Feed
Cleaning Method
Manual Wipe (Hinged Door Access)
Applications
Flour, Sugar, Plastic Pellets, Grain
FAQs About VIBRA® Bullet Magnets
What are bullet magnets used for?
They sit in the center of the pipe to capture tramp metal from flour, sugar, or plastic pellets.
Why is it shaped like a bullet?
How do I clean the magnet?
The magnet is mounted on a hinged door; simply swing it out to wipe captured metal off safely.
Can it handle high pressure?
Designed for vacuum and pressure lines, the sealed unit prevents leaks while maintaining separation efficiency.
Is it food safe?
Fully welded and polished construction meets hygiene standards for food, beverage, and pharmaceutical processing applications.
What sizes are available?
We can also custom manufacture flanges and housing dimensions to fit your specific existing pipeline requirements.
We Provide Few Options
Food standards options available
We offer food standards options to ensure safety and compliance in various industries.
Customized design
Our customization options allow you to create magnets that are uniquely yours.
Available in custom sizes, strengths, and materials
Select from a range of custom sizes, strengths, and materials to suit your specific requirements.
Various services available
Services such as Magnet Measuring and Calibration are available.
Industrial Applications
Trusted in critical processes across diverse manufacturing sectors
Food & Beverage Processing
Pharmaceutical
Recycling
Ceramics
Wood Processing
Glass Processing
Plastic
Plastic Processing
